Ubiquiti UniFi Dream Machine Special Edition (UDM-SE) Cloud Gateway

The Ubiquiti UniFi Dream Machine Special Edition (UDM-SE) is an all-in-one enterprise network gateway combining a security gateway, UniFi Network controller, UniFi Protect NVR, and PoE switch in a single 1U rack-mountable unit. With eight Gigabit PoE+ ports, two 10GbE SFP+ uplinks, a built-in 3.5-inch HDD bay, and a 1.3-inch LCD display, it is the centerpiece of a complete UniFi wired, wireless, and security deployment.

Key Features

• 8x Gigabit PoE+ ports (802.3at) + 2x 10GbE SFP+ uplinks
• Built-in UniFi Network controller, UniFi Protect NVR, and security gateway
• 3.5-inch HDD bay for local UniFi Protect camera storage
• 1.3-inch LCD display for real-time system status
• 1U rack-mountable with front-to-back airflow

Product Specifications

• Part Number: UDM-SE
• Manufacturer: Ubiquiti
• Model: UniFi Dream Machine Special Edition
• Access Ports: 8x 1GbE PoE+ (802.3at)
• Uplink Ports: 2x 10GbE SFP+
• Storage Bay: 1x 3.5-inch SATA HDD (not included)
• Form Factor: 1U Rack-mountable
• Display: 1.3-inch LCD

Switch & Port Specifications

• PoE Standard: 802.3at (PoE+, up to 30W per port)
• Total PoE Budget: 120W
• Switching Capacity: 36 Gbps
• WAN Ports: 1x 10GbE SFP+ (configurable)
• Console Port: USB-C

Network & Protocol Specifications

• Routing: Static, OSPF, policy-based routing
• VPN: Site-to-site VPN, Teleport VPN
• Security: IDS/IPS, DPI, traffic shaping, firewall
• UniFi Applications: Network, Protect, Access (with license)
• Management: UniFi Network app, UniFi OS console

Use Cases

• All-in-one UniFi gateway, switch, and NVR for small to mid-size deployments
• Rack-mounted UniFi controller for managing UniFi APs, switches, and cameras
• Local UniFi Protect NVR for IP camera recording without a separate server
• PoE+ switching for UniFi APs, IP cameras, and VoIP phones

Compatibility

• Manages UniFi network devices including APs, switches, and cameras via UniFi OS
• Compatible with standard 3.5-inch SATA HDDs for UniFi Protect storage
• Supports standard 10GbE SFP+ transceivers and DAC cables for uplinks

Frequently Asked Questions

Does the UDM-SE include a hard drive?

No — the 3.5-inch HDD bay is empty. A compatible SATA HDD must be purchased separately for UniFi Protect camera recording.

Can the UDM-SE replace a separate UniFi controller?

Yes — the UDM-SE runs UniFi OS and hosts the UniFi Network controller natively, eliminating the need for a separate Cloud Key or server-based controller.

What is the total PoE budget?

The UDM-SE provides 120W total PoE budget across all eight 802.3at PoE+ ports.

The Ubiquiti UDM-SE is the ultimate all-in-one UniFi platform for rack-mounted enterprise deployments. Order today and consolidate your gateway, controller, NVR, and PoE switching into a single powerful unit.
