Samsung PM9A3 7.68TB PCIe 4.0 x4 NVMe 1.4 V-NAND TLC U.2 2.5-inch Enterprise SSD — MZQL27T6HBLA-00A07

The Samsung PM9A3 (MZQL27T6HBLA-00A07) is a high-capacity 7.68TB PCIe 4.0 x4 NVMe 1.4 enterprise solid state drive in the U.2 2.5-inch form factor, featuring Samsung V-NAND TLC technology. The 00A07 suffix denotes a specific OEM/channel production revision of the PM9A3 7.68TB family, delivering exceptional PCIe Gen4 NVMe bandwidth with enterprise-grade reliability and Power Loss Protection for demanding data center workloads.

Key Features

• 7.68TB high-capacity enterprise NVMe SSD in U.2 form factor
• PCIe 4.0 x4 NVMe 1.4 for maximum Gen4 data center bandwidth
• Samsung V-NAND TLC for enterprise-grade endurance and reliability
• U.2 2.5-inch form factor for standard enterprise server drive bays
• Power Loss Protection (PLP) for enterprise data integrity
• OEM/channel variant — 00A07 production revision

Product Specifications

• Part Number: MZQL27T6HBLA-00A07
• Manufacturer: Samsung
• Model: PM9A3 (00A07 OEM revision)
• OEM Status: Genuine Samsung OEM
• Capacity: 7.68TB
• Interface: PCIe 4.0 x4 NVMe 1.4
• Form Factor: U.2 2.5-inch
• NAND Type: Samsung V-NAND TLC
• Power Loss Protection: Yes (PLP)
• Use Case: Mixed-Use

Storage Specifications

• Capacity: 7.68TB
• Interface: PCIe 4.0 x4 NVMe 1.4
• Form Factor: U.2 2.5-inch (SFF-8639 connector)
• NAND Type: Samsung V-NAND TLC
• Power Loss Protection: Yes
• Production Revision: 00A07

Performance Specifications

• Sequential Read: Up to 6,800 MB/s
• Sequential Write: Up to 4,000 MB/s
• Random Read (IOPS): Up to 1,000K
• Random Write (IOPS): Up to 180K
• DWPD: 1 (mixed-use rated)
• MTBF: 2,000,000 hours

Use Cases

• Mixed-use data center NVMe storage
• OEM server platform NVMe storage integration
• Database and transactional workload storage
• Virtualization host NVMe storage
• High-capacity NVMe storage array deployments

Compatibility

• Compatible with servers supporting PCIe 4.0 x4 NVMe U.2 (SFF-8639) drives
• U.2 form factor requires SFF-8639 connector
• Compatible with Windows Server, Linux, and VMware ESXi
• Verify server U.2 bay and PCIe Gen4 support before ordering

Frequently Asked Questions

What is the difference between MZQL27T6HBLA-00A07 and MZ-QL27T600 / MZ-QL27T60?

All three are Samsung PM9A3 7.68TB PCIe 4.0 NVMe U.2 SSDs. MZQL27T6HBLA-00A07 is a specific OEM/channel variant with the 00A07 production revision suffix, while MZ-QL27T600 and MZ-QL27T60 are standard retail part numbers — they are functionally equivalent with the same specifications.

What is the sequential read speed of the Samsung PM9A3 MZQL27T6HBLA-00A07?

The Samsung PM9A3 delivers sequential read speeds of up to 6,800 MB/s on PCIe 4.0 systems.

Does this drive support Power Loss Protection?

Yes, the Samsung PM9A3 features PLP (Power Loss Protection) using onboard capacitors to ensure data integrity during unexpected power failures.

The Samsung PM9A3 (MZQL27T6HBLA-00A07) is a high-capacity enterprise NVMe SSD delivering 7.68TB of PCIe Gen4 storage for demanding data center workloads. Order today for proven Samsung V-NAND enterprise reliability in this specific OEM variant.
