Samsung PM1655 1.6TB SAS 24Gb/s Mixed Use V-NAND TLC 2.5-inch Enterprise SSD

The Samsung PM1655 (MZILG1T6HCJRAD3) is a 1.6TB SAS 24Gb/s Mixed Use enterprise SSD built on Samsung V-NAND TLC technology. Delivering next-generation SAS 24Gb/s bandwidth with enterprise Mixed Use endurance, it is designed for high-throughput database, virtualization, and AI/ML storage workloads in enterprise servers and all-flash storage arrays requiring maximum SAS interface performance.

Key Features

• 1.6TB Mixed Use capacity for balanced read/write enterprise workloads
• SAS 24Gb/s — next-generation SAS interface doubling SAS 12Gb/s bandwidth
• Samsung V-NAND TLC for enterprise-class endurance and reliability
• Dual-port SAS for high-availability multipath server configurations
• 2.5-inch SFF hot-swap form factor for enterprise server and array bays

Product Specifications

• Part Number: MZILG1T6HCJRAD3
• Manufacturer: Samsung
• Model: PM1655
• Capacity: 1.6TB
• Interface: SAS 24Gb/s
• NAND: Samsung V-NAND TLC
• Use Case: Mixed Use
• Form Factor: 2.5-inch SFF

Storage Specifications

• Capacity: 1.6TB
• Interface: SAS 24Gb/s (dual-port)
• NAND Type: Samsung V-NAND TLC
• Form Factor: 2.5-inch SFF hot-swap
• Sector Size: 512e / 4Kn
• Encryption: AES-256 self-encrypting (SED)

Performance Specifications

• Sequential Read: Up to 4,200 MB/s
• Sequential Write: Up to 1,400 MB/s
• Random Read: Up to 800,000 IOPS
• Random Write: Up to 200,000 IOPS
• Endurance: Mixed Use rated (3 DWPD typical)

Use Cases

• Enterprise database servers requiring maximum SAS 24Gb/s sequential throughput
• All-flash storage array expansion with high-endurance Mixed Use SAS SSD
• Virtualization host storage for VMware ESXi and Hyper-V high-IOPS workloads
• AI/ML storage nodes requiring high sequential bandwidth from SAS 24Gb/s

Compatibility

• SAS 24Gb/s HBAs and RAID controllers with SAS 24Gb/s expander support
• Backward compatible with SAS 12Gb/s controllers (at 12Gb/s speed)
• 2.5-inch SFF hot-swap bays in enterprise servers and JBODs
• AES-256 SED for FIPS-compliant data-at-rest encryption environments

Frequently Asked Questions

What is SAS 24Gb/s and how does it differ from SAS 12Gb/s?

SAS 24Gb/s doubles the per-lane bandwidth of SAS 12Gb/s — providing up to 4,200 MB/s sequential read on the PM1655 vs approximately 1,000 MB/s on typical SAS 12Gb/s SSDs. Requires SAS 24Gb/s HBA or RAID controller.

Is the PM1655 backward compatible with SAS 12Gb/s?

Yes — the PM1655 operates in SAS 12Gb/s controllers at reduced speed. Full SAS 24Gb/s performance requires a SAS 24Gb/s HBA or RAID controller.

What DWPD endurance does the PM1655 Mixed Use offer?

The Samsung PM1655 Mixed Use is rated at approximately 3 DWPD (Drive Writes Per Day) — suitable for balanced read/write workloads in database, virtualization, and analytics environments.

The Samsung PM1655 (MZILG1T6HCJRAD3) delivers 1.6TB SAS 24Gb/s Mixed Use enterprise SSD performance with V-NAND TLC and dual-port SAS — purpose-built for high-throughput database, all-flash array, and AI/ML storage workloads. Order today for fast shipping.
