Juniper EX4100-F-12T 12-Port Gigabit Layer 3 Managed Switch with 4 SFP+ Uplinks

The Juniper EX4100-F-12T is a 12-port 10/100/1000BASE-T Gigabit Layer 3 managed switch with 4 SFP+ (10GbE) uplinks, running Juniper Junos OS. Designed for small enterprise and branch office access layer deployments, it delivers full Layer 3 routing, Virtual Chassis stacking, and Junos-powered automation in a compact rack-mountable form factor — with PoE+ support for powering connected devices.

Key Features

• 12x Gigabit RJ-45 ports for wired access layer connectivity
• 4x SFP+ (10GbE) uplinks for aggregation layer and uplink flexibility
• Full Layer 3 routing: OSPF, BGP, static routing
• Juniper Virtual Chassis — stack multiple EX4100 switches as a single logical device
• Junos OS with NETCONF, REST, and Junos Space management
• Compact 1U rack-mountable form factor for small branch deployments

Product Specifications

• Part Number: EX4100-F-12T
• Manufacturer: Juniper Networks
• Model: EX4100-F-12T
• Ports: 12x 1GbE RJ-45 + 4x SFP+
• Switching Layer: Layer 3
• Form Factor: 1U Rack-mountable

Switch & Port Specifications

• RJ-45 Ports: 12x 10/100/1000BASE-T
• SFP+ Uplinks: 4x 10GbE
• PoE: PoE+ (802.3at) on select ports
• Switching Capacity: 104 Gbps
• Forwarding Rate: 77.4 Mpps
• MAC Table: 16K entries

Network & Protocol Specifications

• Routing: OSPF, BGP, RIP, static routing
• Stacking: Virtual Chassis
• VLAN: IEEE 802.1Q
• QoS: 8 queues per port, 802.1p, DSCP
• Security: 802.1X, DHCP snooping, Dynamic ARP inspection
• Management: Junos OS CLI, NETCONF, REST, Junos Space

Use Cases

• Small enterprise and branch office Gigabit access layer switching
• Juniper Virtual Chassis deployments for multi-switch logical stacking
• PoE+ access switch for IP phones, APs, and cameras in branch offices
• Layer 3 routing at the access layer for small campus networks

Compatibility

• Standard Cat5e/Cat6 cabling for RJ-45 Gigabit ports
• SFP+ ports: 10GBASE-SR/LR transceivers and DAC/AOC cables
• Virtual Chassis compatible with EX4100 series switches
• Managed via Junos OS CLI, Junos Space, and Juniper Mist for cloud management

Frequently Asked Questions

What does the F suffix mean in EX4100-F-12T?

The F suffix in EX4100-F-12T indicates the fanless model — silent operation suitable for quiet office environments where fan noise is unacceptable.

Does the EX4100-F-12T support PoE?

Yes — select RJ-45 ports support IEEE 802.3at PoE+ for powering IP phones, Wi-Fi access points, and IP cameras. Verify total PoE budget for your deployment.

Can EX4100-F-12T switches be stacked?

Yes — via Juniper Virtual Chassis, multiple EX4100 switches operate as a single logical managed device for simplified administration and redundancy.

The Juniper EX4100-F-12T delivers 12-port Gigabit Layer 3 managed switching with 4 SFP+ uplinks, Virtual Chassis, and Junos OS — a compact, fanless enterprise switch for small branch and office access layer deployments. Order today for fast shipping.
