Juniper 10GBASE-LR SFP+ Transceiver — 10km Single-Mode Fiber

The Juniper SFPP-10G-LR-C is a 10GBASE-LR SFP+ optical transceiver delivering 10GbE over single-mode fiber up to 10km at 1310nm (1355nm variant) via duplex LC connector — Juniper-coded in alphanumeric format for plug-and-play compatibility across Juniper EX, QFX, MX, PTX, and SRX platforms requiring standard 10G SMF connectivity for data center, campus, and service provider applications.

Key Features

• 10GBASE-LR SFP+ for 10km 10GbE over single-mode fiber at 1310/1355nm
• Duplex LC connector for standard OS1/OS2 SMF patch panel compatibility
• Juniper-coded (SFPP-10G-LR-C) for recognized, warning-free operation on Juniper platforms
• DDM/DOM support for real-time optical monitoring via Junos OS
• Low-power SFP+ for energy-efficient 10G SMF deployments

Product Specifications

• Part Number: SFPP-10G-LR-C
• Manufacturer: Juniper Networks
• Form Factor: SFP+
• Speed: 10GbE (10GBASE-LR)
• Wavelength: 1310nm / 1355nm
• Connector: Duplex LC
• Fiber Type: Single-Mode Fiber (SMF, OS1/OS2)

Transceiver & Interface Specifications

• Max Distance: 10km over OS1/OS2 SMF
• TX Power: -8.2 to +0.5 dBm
• RX Sensitivity: -14.4 dBm (min)
• Power Consumption: Typically 1.0W
• DDM/DOM: Yes
• Operating Temperature: 0°C to 70°C (commercial)

Use Cases

• 10GbE SMF uplinks and inter-switch links up to 10km in Juniper EX/QFX campus deployments
• Service provider 10G access and aggregation links on Juniper MX or SRX platforms
• Data center to distribution 10GbE SMF links exceeding MMF reach limitations
• Campus inter-building 10G fiber links over existing OS1/OS2 SMF infrastructure

Compatibility

• Compatible with Juniper EX, QFX, MX, PTX, and SRX platforms with SFP+ 10G ports
• Requires OS1/OS2 single-mode fiber with duplex LC connectors
• IEEE 802.3ae 10GBASE-LR compliant
• Numeric equivalent: 740-140352 — both are interchangeable on supported Juniper platforms

Frequently Asked Questions

What is the difference between SFPP-10G-LR-C and 740-140352?

Both are Juniper-genuine 10GBASE-LR SFP+ transceivers with identical optical specifications. SFPP-10G-LR-C uses the alphanumeric part number format, while 740-140352 uses the numeric format. Both are fully interchangeable on supported Juniper platforms.

What is the difference between SFPP-10G-LR-C and SFPP-10G-SR-C?

The SFPP-10G-LR-C uses 1310nm laser for long-reach SMF connectivity up to 10km, while the SFPP-10G-SR-C uses 850nm VCSEL for short-reach MMF connectivity up to 300m (OM3) or 400m (OM4). Select based on your fiber type (SMF vs. MMF) and link distance requirements.

Does SFPP-10G-LR-C support DDM monitoring?

Yes — DDM/DOM is fully supported, enabling Junos OS to report TX/RX optical power, temperature, voltage, and bias current in real time for proactive transceiver health monitoring via CLI and SNMP.

The Juniper SFPP-10G-LR-C delivers Juniper-coded 10GBASE-LR connectivity over 10km single-mode fiber with DDM monitoring and broad platform compatibility — providing the standard 10G SMF transceiver for Juniper EX, QFX, MX, PTX, and SRX deployments where long-reach fiber connectivity beyond MMF distance limitations is required.
