Juniper 1000BASE-T Copper SFP+ Transceiver — 30m RJ-45

The Juniper 740-083295 is a 1000BASE-T copper SFP+ transceiver delivering GbE over Cat5e/Cat6 copper cabling up to 30m via RJ-45 connector — the numeric part number equivalent to SFP-1G-T-C, for use in Juniper platforms where copper GbE connectivity is needed in SFP/SFP+ port slots.

Key Features

• 1000BASE-T copper transceiver for GbE over Cat5e/Cat6 in Juniper SFP/SFP+ port slots
• RJ-45 connector for direct copper structured cabling compatibility
• Juniper numeric part number (740-083295) — functionally equivalent to SFP-1G-T-C
• 30m copper reach suitable for in-rack and short cross-row copper connections
• Juniper-genuine for verified platform compatibility on EX, MX, QFX, and SRX

Product Specifications

• Part Number: 740-083295
• Manufacturer: Juniper Networks
• Form Factor: SFP+
• Speed: 1GbE (1000BASE-T)
• Connector: RJ-45
• Cable Type: Cat5e / Cat6 copper
• Max Distance: 30m

Transceiver & Interface Specifications

• Auto-negotiation: Yes
• Duplex: Full duplex
• Power Consumption: Typically 0.7W
• DDM/DOM: No (copper transceiver)
• Operating Temperature: 0°C to 70°C (commercial)

Use Cases

• Copper GbE connectivity in Juniper SFP+ port slots for short in-rack or cross-row links
• Connecting Juniper QFX/EX SFP+ ports to copper-cabled servers or network devices
• Numeric part number procurement alternative to SFP-1G-T-C for the same copper GbE SFP application
• Flexible mixed copper/fiber port configurations in Juniper data center and campus deployments

Compatibility

• Compatible with Juniper EX, MX, QFX, and SRX platforms with SFP/SFP+ ports
• Requires Cat5e or Cat6 copper cable with RJ-45 connectors up to 30m
• IEEE 802.3ab 1000BASE-T compliant
• Interchangeable with SFP-1G-T-C on supported Juniper platforms

Frequently Asked Questions

Why does the 740-083295 only support 30m while SFP-1G-T-C supports 100m?

The maximum copper distance listed reflects the qualified reach for the specific transceiver variant. The 30m specification on the 740-083295 reflects the Juniper-tested and supported reach for this numeric variant — for 100m copper GbE requirements, verify with Juniper whether SFP-1G-T-C's 100m rating applies to your platform and cable quality.

Can the 740-083295 be used interchangeably with SFP-1G-T-C on the same Juniper switch?

Yes — both are Juniper-genuine 1000BASE-T copper SFP transceivers and are interchangeable on the same platform. Junos OS recognizes both part numbers without warnings or operational differences.

Does the 740-083295 support PoE?

No — like all copper SFP transceivers, the 740-083295 does not support PoE pass-through. PoE requires dedicated switch port circuitry and cannot be delivered through an SFP transceiver module.

The Juniper 740-083295 provides the numeric part number alternative for Juniper copper GbE SFP connectivity — delivering 1000BASE-T RJ-45 operation in Juniper SFP/SFP+ port slots with the same platform compatibility and Juniper-genuine quality as the SFP-1G-T-C alphanumeric variant.
