Cisco Meraki MR70 Dual-Band 802.11ac Wave 2 Wi-Fi 5 Cloud-Managed Outdoor Access Point

The Cisco Meraki MR70 (MR70-HW) is a dual-band 802.11ac Wave 2 Wi-Fi 5 outdoor access point with 2x2:2 MIMO, designed for cloud-managed outdoor wireless deployments via the Meraki dashboard. Purpose-built for enterprise outdoor environments — campuses, warehouses, stadiums, and industrial sites — it delivers IP67-rated ruggedization, Meraki zero-touch provisioning, and integrated security for reliable outdoor Wi-Fi connectivity.

Key Features

• 802.11ac Wave 2 dual-band (2.4GHz + 5GHz) for outdoor enterprise Wi-Fi
• IP67 rated — fully dust-tight and waterproof for demanding outdoor environments
• Cisco Meraki cloud management — zero-touch provisioning and centralized dashboard
• 2x2:2 MU-MIMO for concurrent multi-device outdoor connectivity
• Integrated Meraki security: IDS/IPS, content filtering, and rogue AP detection
• Wall-mountable for building exterior and outdoor structure deployment

Product Specifications

• Part Number: MR70-HW
• Manufacturer: Cisco Meraki
• Model: MR70
• Wi-Fi Standard: 802.11ac Wave 2 (Wi-Fi 5)
• MIMO: 2x2:2
• Bands: 2.4GHz + 5GHz
• Rugged Rating: IP67
• Management: Meraki Cloud Dashboard

Wireless & Network Specifications

• Max Throughput: Up to 1.3 Gbps (5GHz) + 300 Mbps (2.4GHz)
• MIMO: 2x2:2 MU-MIMO
• Frequency: Dual-band concurrent 2.4GHz and 5GHz
• Encryption: WPA3, WPA2, 802.11i
• SSID: Up to 15 SSIDs per AP
• Security: Integrated IDS/IPS, rogue AP detection, content filtering

Connectivity Specifications

• Ethernet: 1x Gigabit PoE (802.3at PoE+)
• Power: IEEE 802.3at PoE+ (30W)
• Mounting: Wall-mountable (outdoor bracket included)
• IP Rating: IP67 — dust-tight, waterproof
• Operating Temperature: -30°C to 60°C

Use Cases

• Campus outdoor Wi-Fi for student and staff connectivity between buildings
• Warehouse and industrial outdoor Wi-Fi for inventory and logistics operations
• Stadium and venue outdoor wireless for event guest connectivity
• Building exterior Wi-Fi bridging for Meraki cloud-managed outdoor coverage

Compatibility

• Requires active Cisco Meraki Enterprise license for cloud management
• IEEE 802.3at PoE+ switch or injector for power and uplink
• Managed via Cisco Meraki cloud dashboard — zero-touch provisioning
• Compatible with Meraki MX security appliances for Auto VPN

Frequently Asked Questions

Does the MR70 require a Meraki license?

Yes — an active Cisco Meraki Enterprise license is required. Without a license, the MR70 cannot be managed via the Meraki dashboard.

What is the IP67 rating?

IP67 means the MR70 is fully dust-tight (IP6X) and waterproof to 1 meter submersion for 30 minutes (IPX7) — suitable for direct rain exposure and harsh outdoor environments.

What power does the MR70 require?

The MR70 requires IEEE 802.3at PoE+ (30W) — a PoE+ capable switch port or injector is required. Standard 802.3af PoE (15.4W) is insufficient.

The Cisco Meraki MR70 (MR70-HW) delivers IP67-rated dual-band 802.11ac Wave 2 outdoor Wi-Fi with Meraki cloud management — purpose-built for campus, warehouse, and industrial outdoor wireless deployments. Order today for fast shipping.
